IMOU IPC-PS3DP 3MP Bullet PoE CCTV Camera
3MP High-Resolution Video
The IMOU IPC-PS3DP 3MP Bullet PoE CCTV Camera delivers detailed surveillance footage at up to 2304 × 1296 resolution. Its 3MP image quality provides clear video for monitoring entrances, compounds, shops, offices, parking areas and other important locations.
The camera uses a 1/3-inch Progressive CMOS sensor and supports efficient H.265/H.264 video compression to help reduce storage and bandwidth requirements.
Night Vision & Illumination
The camera is designed for 24-hour surveillance, providing visibility in low-light and nighttime conditions. Its illumination range reaches up to 30 metres, helping monitor outdoor areas after dark.
A built-in spotlight provides additional illumination when required, making the camera suitable for areas that need reliable nighttime monitoring.
Human & Vehicle Detection
The IPC-PS3DP supports human detection and vehicle detection, helping identify important movement within the camera’s viewing area. It also supports motion detection for general activity monitoring.
These smart detection functions can make recorded footage easier to review by focusing attention on relevant events.
PoE Connectivity
One of the key advantages of this camera is its Power over Ethernet (PoE) capability. Using a compatible PoE switch or PoE NVR, both power and network data can be transmitted through a single Ethernet cable.
This simplifies installation by reducing the number of cables required between the camera and network equipment.
The camera also supports 12V DC power, providing an alternative where PoE equipment is not available.
Storage Options
The IMOU IPC-PS3DP supports Micro SD card storage up to 512GB, allowing video recordings to be stored locally.
It can also be integrated into compatible network video surveillance systems. Its ONVIF support provides additional compatibility with suitable third-party surveillance equipment.
Outdoor Weather Protection
Designed for outdoor surveillance, the camera features an IP67-rated housing, providing protection against dust and water. This makes it suitable for installation in outdoor areas exposed to changing weather conditions.
The camera operates in temperatures from approximately -30°C to +60°C, making it suitable for a wide range of outdoor environments.
Audio Support
The camera includes a built-in microphone, allowing audio to be captured together with compatible video recordings. This can provide additional information when monitoring entrances, shops, offices and other areas.
Technical Specifications
| Specification | Details |
|---|---|
| Model | IMOU IPC-PS3DP-3M0 |
| Camera Type | Bullet PoE IP Camera |
| Resolution | 3MP |
| Maximum Resolution | 2304 × 1296 |
| Image Sensor | 1/3″ Progressive CMOS |
| Lens | 2.8mm / 3.6mm Fixed Lens |
| Aperture | F1.6 |
| Night Illumination | Up to 30m |
| Video Compression | H.265 / H.264 |
| Digital Zoom | 8× |
| Detection | Motion, Human & Vehicle Detection |
| Audio | Built-in Microphone |
| Storage | Micro SD up to 512GB |
| Network | 100Mbps Ethernet |
| Connectivity | PoE |
| Power | PoE / 12V DC 1A |
| Power Consumption | Less than 6W |
| Weather Protection | IP67 |
| Operating Temperature | -30°C to +60°C |
| ONVIF | Supported |
| Mobile App | IMOU App |
Lens options and some specifications can vary according to the exact IPC-PS3DP version.
Key Features
- 3MP high-resolution video for detailed surveillance footage.
- PoE connectivity for convenient single-cable power and data transmission.
- Up to 30m nighttime illumination for 24-hour monitoring.
- Human and vehicle detection for smarter event monitoring.
- Up to 512GB Micro SD support for local video storage.
- IP67 outdoor protection for reliable outdoor installation.
Ideal Applications
The IMOU IPC-PS3DP is suitable for:
- Homes and residential compounds
- Shops and retail stores
- Offices
- Warehouses
- Schools and institutions
- Parking areas
- Building entrances
- Gates and driveways
- Commercial premises
- Outdoor perimeter surveillance
